Ganita Manjari · Class 9 · Part II · Chapter 14

Ganita Manjari Class 9 Maths Chapter 14 Math of Space: Surface Area and Volume Exercise 14.3 Solutions

Nine questions on cones: surface areas, volume, a joker's cap, a tent, a solid of revolution and a cup filled to half its depth.

Last updated 7 October 2026

  • 9Questions
  • 9Diagrams
  • Ch 14Math of Space: Surface Area and Volume

How to answer every question

CSA = πrl, V = ⅓πr²h
  1. Find the slant height l = √(h² + r²) by the Baudhāyana–Pythagoras theorem.
  2. Choose the formula CSA = πrl, TSA = πr(l + r), V = ⅓πr²h.
  3. Check the open end A cap or tent has no base, so use the curved surface only.
  4. Keep the unit Areas are in square units, volumes in cubic units.

Slant height: the length along the cone's surface from the apex to the rim.

CSA of a cone: πrl.

Volume of a cone: one third of the base area times the height.

Cones

Chapter 14 Exercise 14.3 Question 1 Solution : Find the total surface area of a cone with slant height 21 m and base diameter 24 m. (π ≈ 227)

Answer: ≈ 1244.57 m²
Cone with slant height 21 m and diameter 24 mA cone with base radius 12 m, slant height 21 m.hr = 12 ml = 21 mapexd = 24 m, so r = 12 ml = 21 mTSA = πr(l + r)= (22/7) × 12 × 33≈ 1244.57 m²
Q1 · the cone

Solution:

Diameter = 24 m, so radius r = 12 m. Slant height l = 21 m.

TSA = πr(l + r)

∴ TSA = 227 × 12 × (21 + 12) = 227 × 12 × 33

∴ TSA = 87127 ≈ 1244.57 m2

(With π = 3.14 the answer is 1243.44 m2.)

The total surface area is about 1244.57 m² (87127 m²).

Chapter 14 Exercise 14.3 Question 2 Solution : Find the curved surface area of a cone with slant height 10 cm and base radius 7 cm.

Answer: 220 cm²
Cone with slant height 10 cm and radius 7 cmA cone with base radius 7 cm and slant height 10 cm.hr = 7 cml = 10 cmapexCSA = πrl= (22/7) × 7 × 10= 220 cm²
Q2 · the cone

Solution:

l = 10 cm, r = 7 cm

CSA = πrl

∴ CSA = 227 × 7 × 10

∴ CSA = 220 cm2

The curved surface area is 220 cm².

Chapter 14 Exercise 14.3 Question 3 Solution : The height of a cone is 16 cm and its base radius is 12 cm. Find the curved and total surface areas.

Answer: 240π and 384π
Cone with height 16 cm and radius 12 cmA cone with height 16 cm and radius 12 cm. The slant height is 20 cm from the right triangle with sides 16 and 12.h = 16 cmr = 12 cml = ?apexl² = h² + r² = 256 + 144 = 400l = 20 cmCSA = πrl = 240π cm²TSA = πr(l + r) = 384π cm²
Q3 · the cone

Solution:

h = 16 cm, r = 12 cm

Slant height l = √(h2 + r2) = √(256 + 144) = √400

∴ l = 20 cm

CSA = πrl = π × 12 × 20

∴ CSA = 240π cm2 ≈ 753.6 cm2 (π = 3.14)

TSA = πr(l + r) = π × 12 × (20 + 12)

∴ TSA = 384π cm2 ≈ 1205.76 cm2 (π = 3.14)

CSA = 240π ≈ 753.6 cm² and TSA = 384π ≈ 1205.76 cm².

Chapter 14 Exercise 14.3 Question 4 Solution : A cone has height 15 cm and volume 1570 cm³. Find the radius of the base. (π = 3.14)

Answer: 10 cm
Cone with height 15 cm and volume 1570 cubic centimetresA cone of height 15 cm and unknown radius, with volume 1570 cubic centimetres.h = 15 cmr = ?apexV = (1/3)πr²h1570 = (1/3)(3.14) r² (15)r² = 100r = 10 cm
Q4 · the cone

Solution:

h = 15 cm, V = 1570 cm3, π = 3.14

V = 13πr2h

∴ 1570 = 13 × 3.14 × r2 × 15

∴ 1570 = 15.7 r2

∴ r2 = 157015.7 = 100

∴ r = 10 cm

The radius is 10 cm.

Chapter 14 Exercise 14.3 Question 5 Solution : The curved surface area of a cone is 308 cm² and its slant height is 14 cm. Find (i) the radius, (ii) the total surface area.

Answer: r = 7 cm; TSA = 462 cm²
Cone with curved surface area 308 and slant height 14 cmA cone with slant height 14 cm and curved surface area 308 square centimetres.hr = ?l = 14 cmapexCSA = πrl = 308(22/7) × r × 14 = 30844 r = 308, so r = 7 cmTSA = πr(l + r) = 462 cm²
Q5 · the cone

Solution:

CSA = 308 cm2, l = 14 cm

(i) CSA = πrl

∴ 308 = 227 × r × 14 = 44r

∴ r = 30844 = 7 cm

(ii) TSA = πr(l + r) = 227 × 7 × (14 + 7)

∴ TSA = 227 × 7 × 21 = 462 cm2

Check: base area πr2 = 154, and 308 + 154 = 462 ✓

(i) 7 cm, (ii) 462 cm².

Chapter 14 Exercise 14.3 Question 6 Solution : A joker's cap is a cone of base radius 7 cm and height 24 cm. Find the area of sheet for 10 caps.

Answer: 5500 cm²
Joker cap, a cone of radius 7 cm and height 24 cmA cone-shaped cap with radius 7 cm, height 24 cm and slant height 25 cm.h = 24 cmr = 7 cml = 25 cmapexl = √(24² + 7²) = √625 = 25 cmSheet for one cap = CSA= πrl = (22/7) × 7 × 25 = 550 cm²10 caps = 5500 cm²
Q6 · the cone

Solution:

r = 7 cm, h = 24 cm

Slant height l = √(242 + 72) = √(576 + 49) = √625

∴ l = 25 cm

A cap is open at the bottom, so only the curved surface needs sheet.

CSA of one cap = πrl = 227 × 7 × 25 = 550 cm2

∴ Sheet for 10 caps = 10 × 550 = 5500 cm2

The sheet needed is 5500 cm².

Chapter 14 Exercise 14.3 Question 7 Solution : What length of tarpaulin 3 m wide is needed for a conical tent of height 8 m and base radius 6 m? Allow an extra 20 cm length for stitching and wastage. (π ≈ 227)

StarredAnswer: about 63.06 m
Conical tent of height 8 m and radius 6 mA conical tent with height 8 m, radius 6 m and slant height 10 m.h = 8 mr = 6 ml = 10 mapexl = √(8² + 6²) = 10 mCSA = πrl = (22/7) × 6 × 10≈ 188.57 m²length = area ÷ 3 m ≈ 62.86 m+ 0.2 m → 63.06 m
Q7 · the cone

Solution:

h = 8 m, r = 6 m, width of tarpaulin = 3 m

Slant height l = √(82 + 62) = √100 = 10 m

Area of tent = CSA = πrl = 227 × 6 × 10

∴ Area = 13207 ≈ 188.57 m2

Area of tarpaulin = width × length

∴ length = 13207 × 3 = 4407 ≈ 62.86 m

Add the extra 20 cm = 0.2 m for stitching and wastage.

∴ Total length = 62.86 + 0.2 = 63.06 m

About 63.06 m of tarpaulin is needed.

Chapter 14 Exercise 14.3 Question 8 Solution : A right triangle with sides 6 cm, 8 cm and 10 cm is rotated through 360° about the side of 8 cm. Find the volume and the curved surface area of the solid.

Answer: V = 96π; CSA = 60π
A right triangle with sides 6, 8, 10 rotated about the side of 8 cmThe right triangle with legs 6 cm and 8 cm is turned through 360 degrees about the 8 cm leg and sweeps out a cone of height 8 cm, radius 6 cm and slant height 10 cm.axis8 cm6 cm10 cmturn 360°h = 8r = 6l = 10V = (1/3)πr²h= (1/3)π(36)(8) = 96π≈ 301.44 cm³CSA = πrl = 60π≈ 188.4 cm²
Q8 · the cone

Solution:

The triangle turns about the 8 cm side, so the solid is a cone.

h = 8 cm, r = 6 cm, l = 10 cm (the hypotenuse)

V = 13πr2h = 13 × π × 36 × 8

∴ V = 96π cm3 ≈ 301.44 cm3 (π = 3.14)

CSA = πrl = π × 6 × 10

∴ CSA = 60π cm2 ≈ 188.4 cm2 (π = 3.14)

Volume 96π ≈ 301.44 cm³ and curved surface area 60π ≈ 188.4 cm².

Chapter 14 Exercise 14.3 Question 9 Solution : A cup is a right circular cone. It is filled with water to half the depth. What fraction of the cup's volume does the water fill?

StarredAnswer: one eighth
A girl thinking next to a conical cup that is partly filled with water.
Q9 · a cone-shaped cup filled to half its depth (from the book)
A cone filled to half its depthThe water forms a small cone with half the height and half the radius of the cup, so its volume is one eighth of the cup.Q9 · half the depth means half the radius, so one eighth of the volumeHH/2radius Rradius R/2volume = (one half) cubed = one eighthof the full cup
Q9 · half the depth means half the radius

Solution:

Let the cup have height H and radius R.

The water is filled to half the depth, so it forms a smaller cone of height H2.

By similar triangles, the radius of the water surface = R2.

Volume of water = 13π(R2)2(H2)

Volume of cup = 13πR2H

∴ Volume of waterVolume of cup = 14 × 12 = 18

The water fills 18 of the cup.

Answers at a glance

For a cone, find l first.

QuestionWhat is askedKey ideaAnswer
Q1 TSA of a coneπr(l + r)1244.57 m²
Q2 CSAπrl220 cm²
Q3 From h and rl = 20CSA 240π, TSA 384π
Q4 Radius from volume⅓πr²h = 157010 cm
Q5 From CSAπrl = 308r = 7 cm; TSA 462 cm²
Q6 Ten caps10 × πrl5500 cm²
Q7 TarpaulinArea over width + 0.263.06 m
Q8 Rotate 6-8-10 triangleh = 8, r = 6, l = 1096π; 60π
Q9 Cup half fullSimilar cones1/8

Source of the questions: NCERT, Ganita Manjari, Grade 9, Part II, Chapter 14, Exercise Set 14.3. The solutions, explanations and diagrams on this page are our own working.
